.CORE

The .CORE integrated heads are the essence of what makes norwix industrial printing solutions so successful—rugged design, solid connections to external elements and the finest print heads in the industry, all provided in a commercial off-the-shelf system.

norwix Integrated heads are enclosed in an industrialized stainless steel casing for maximum protection.  Up to four print heads are accommodated within to give a 2” print swath.  Seamlessly included in this rugged housing is a print controller and a bulk ink system.





  • Fully integrated system including, pens, print controller and bulk ink system for lowest cost operation
  • Industrial housing for the most arduous environments
  • Variable and fixed data capability – can take data from external sources
  • Large selection of standard and custom inks in black or in color
Specs
Print TechnologyThermal InkJet (TIJ)
Max Print Height 2" maximum (supports up to 16")
Printable ItemsLot Codes, Datecodes, Alphanumeric, Barcodes, Bitmaps
Barcode PrintingEAN-13/EAN 8, UPC-A, Code128, ITF-14, ITF-2of5, Code39, Crypotcode, GS1 Datamatrix, QR  (114 barcode support included)
Print Speedsup to 500fpm @300dpi
Print resolution600/600 dpi max
Print Densityuser configurable
Ink TypesAqueous and Solvent
Bulk Ink AvailableYes
ConnectivityEthernet, I/O, Sensor, Encoder, Stack Light Daisy Chain
Voltage115V to 240V
Software IncludedProducer and Director (Enterprise grade)
LanguagesEnglish, Spanish, German, French
WarrantyLifetime Warranty
Benefits

Designed for Case Coding

  • Turnkey solution for easy integration into existing lines
  • Industrial Design for rugged environments
  • Bulk ink solution as standard to reduce operational costs
  • Easy to operate
  • No Maintenance, No mess solution
  • Up to 600 dpi print resolution for stunning barcodes, graphics and alphanumeric
  • Replaces labels at a fraction of the cost

Managed Print

  • Improved ease of use – no need to program ink drive parameters
  • Print drive parameters pre-set to optimize each inks performance and efficiency
  • Ink tracking and cartridge type awareness
  • Enables full functionality of the software
  • Ability to fine tune drive parameters for specialized applications
  • Expanded maintenance and recovery features to keep cartridges working in the most difficult applications

Lifetime Warranty

  • All products from cables to screens to print heads have a Lifetime Warranty
    • No exclusions on labor or hardware
  • A guarantee of reliability for life
  • If there is ever a problem, we will replace it free of charges for the Lifetime of that product whether 1 year or 10 years from now.
