The high resolution iM2 and iM4 UV Curable Printers provide a versatile, cost-effective solution to meet the need for variable data printing on a range of coated and uncoated substrates. Capable of printing addresses, barcodes, 2D codes, QR codes, numbering, logos and graphics, both the iM2 and iM4 are suitable for mailing and addressing applications, as well as labels, tickets, security, plastic cards and business form applications.
High Quality, High Speed
The iM Series supports up to 600 dpi resolution giving you maximum quality at all times—there is little that cannot be printed with incredible sharpness.
- 600 DPI Print Resolution (1280 print nozzles)
- Variable Drop Size Capability
- Up to 1200 fpm Line Speed
Premium Capabilities at a Lower Cost
The iM2 and iM4 initial cost is significantly lower than other solutions, but this goes beyond just hardware costs. Factoring in reduced maintenance, efficient use of inks, and reliability, both models have a incredibly low Total Cost of Ownership.
- Lowest Cost UV Curable Print Solution
- Quickest ROI in the Industry
- Reduced Operational Costs
Simple to Integrate
With compact footprint and flexible mounting options upgrading existing print solutions with the iM2 is a straightforward process. Using 80/20 as the mounting bar, custom width mounts can be accommodated to meet any installation.
- Installs Quickly into Existing Machinery
- Precision Mounting Gives Exact Control
- Small Footprint Allows for Implementing Multiple Head installations
Print in All Directions
With the patented Ink Delivery System, the iM2 and iM4 can print in any orientation, down, sideways or even upside down. It will also print in shuttling systems without any effort.
Print Technology | Piezo |
Max Print Width | 2.13”/54mm (iM2) 4.26″/108mm (iM4) |
No of Drops | 1 to 3 |
Drop Level (1/2/3) | 7 pl / 14 pl / 24 pl |
Frequency Response | 60kHz. |
Custom Colors | Yes |
Smallest Readable Font Size | 3pt |
Print Speed @ 150dpi | 1200 fpm (356 mpm) |
Print Speed @ 300dpi | 900 fpm (274 mpm) |
Print Speed @ 600dpi | 450 fpm (137 mpm) |
Ink Type | UV |
Communication | Ethernet |
Power Requirement | 240/115 V AC |
Warranty | 12 Months |
- High Speed – over 1500 fpm
- Premium Quality at a lower cost
- Compact Size
- Ease of Use
- Groundbreaking design
